Thermaltake Divider 370 TG ARGB Mid Tower Chassis
Thermaltake designed a brand-new case series that containing stylish side panels and powerful airflow performance blending all the functionality into the Divider Series.
Modern design with Divider 370 TG ARGB’s left panel gives the chassis a unique look while offering a great view of the interior. With three pre-installed ARGB PWM fans, you can enhance the cooling performance with exceptional customizable lighting. The Divider 370 TG ARGB Mid Tower Chassis is the next-gen gaming PC case for regular users, enthusiasts, and gamers, giving them unprecedented satisfaction.
- The image is for reference only.
The exceptional feature of the Divider 370 TG ARGB is that the unique panel that comprised of a steel panel and a 3mm tempered glass window on the left side. The side panel is visually divided to create an unique look, and it is tool-free and easy to remove. Tempered glass window is thicker and more scratch-resistant compared to standard acrylic.
The Divider 370 TG ARGB comes with a large airflow-optimized stylish mesh panel at the front, offering a unique divided design and additional air intake through the mesh.
The Divider 370 TG ARGB comes with three pre-installed hydraulic bearing 120mm ARGB PWM fans which can effectively lower the operation noise and enhance thermal efficiency. The fans’ lighting effect can be either controlled by the physical RGB button on the I/O panel or motherboard software from ASUS, GIGABYTE, MSI, and ASRock. There are 27 RGB lighting modes to play around with when using the physical RGB button, and it’s simple to switch between physical button control and motherboard software control by long pressing the RGB button for three seconds.
The built-in PSU cover is designed to hide unsightly cables with overall good ventilation. The pre-installed GPU holder enables vertical GPU installation, but also helps reduce the weight on the PCI-E slots.
The Divider 370 TG ARGB has a well-designed removable magnetic fan filter on the top and the inner right side. At the base, the removable filter provides excellent dust protection and dirt reduction, ensuring a dust-free environment.
- The image is for reference only.
The cooling performance of the Divider 370 TG ARGB is excellent. The large airflow-optimized mesh panel at the front allow optimal air intake. Cooling exhausts are located at the rear of the case. On the top and right side, there are venting mechanisms for air intake or exhaust depends on the user’s overall PC layout design.
- The image is for reference only.
- 120mm
- 140mm
- 120mm
- 140mm
- 240mm
- 280mm
- 360mm
Two USB 3.0 and one HD Audio jack is placed on the top panel to grant direct access when needed.
120 Series | 240 Series | 360 Series | 140 Series | 280 Series | 420 Series | |
---|---|---|---|---|---|---|
Front | ● | ● | ● | ● | ● | - |
Top | ● | ● | ● | ● | ● | - |
M/B Side | ● | ● | - | - | - | - |
Rear | ● | - | - | - | - | - |
120mm | 140mm | 200mm | |
---|---|---|---|
Front | 3 | 3 | - |
Top | 3 | 2 | - |
M/B Side | 2 | - | - |
Rear | 1 | - | - |
Sync with Motherboard RGB Software
Designed to synchronize with ASUS Aura Sync, GIGABYTE RGB Fusion, MSI Mystic Light Sync, and ASRock Polychrome. It supports motherboards with a 5V addressable RGB header, allowing you to control the lights directly from the software mentioned above without installing any extra lighting software or controllers. For more details, please visit ASUS, GIGABYTE, MSI, and ASRock official websites.
-
Aura Addressable Header
ASUS -
Digital Pin Header
GIGABYTE -
JRAINBOW Header
MSI -
Addressable RGB LED Header
ASRock
Category | Caution |
Chassis, ARGB Fan, ARGB AIO |
|
RGB Memory, VGA Waterblock, Distro Plate |
|
P/N | CA-1S4-00M1WN-00 |
---|---|
Series | Divider |
Case Type | Mid Tower |
Dimension (H x W x D) | 491 x 220.3 x 469.1 mm (19.3 x 8.7 x 18.5 inch) |
Net Weight | 7.44 kg / 16.4 lbs. |
Side Panel | 3mm Tempered Glass x 1 |
Color | Black |
Material | SPCC |
Cooling System | Front(intake): 120 x 120 x 25 mm ARGB PWM fan (1500rpm, 27.2 dBA) x 2 Rear(exhaust): 120 x 120 x 25 mm ARGB PWM fan (1500rpm, 27.2 dBA) x 1 |
Drive Bays -Accessible -Hidden |
2 x 3.5”, 2 x 2.5” or 4 x 2.5” |
Expansion Slots | 7 |
Motherboards | 6.7" x 6.7" (Mini ITX), 9.6" x 9.6" (Micro ATX), 12" x 9.6" (ATX), 12" x 13" (E-ATX) |
I/O Port | USB 3.0 x 2, HD Audio x 1 |
PSU | Standard PS2 PSU (optional) |
Fan Support | Front: 3 x 120mm, 2 x 120mm, 1 x 120mm 3 x 140mm, 2 x 140mm, 1 x 140mm Top: 3 x 120mm, 1 x 120mm 2 x 140mm, 1 x 140mm Right (M/B Side): 2 x 120mm, 1 x 120mm Rear: 1 x 120mm |
Radiator Support | Front: 1 x 360mm, 1 x 240mm, 1 x 120mm 1 x 280mm, 1 x 140mm Top: 1 x 360mm, 1 x 240mm, 1 x 120mm 1 x 280mm, 1 x 140mm Right (M/B Side): 1 x 240mm, 1 x 120mm Rear: 1 x 120mm |
Clearance | CPU cooler max height: 170mm VGA max length: 340mm (with radiator) 400mm (without radiator) PSU max length: 230mm (with HDD Cage) |
